Die Cutting Machine

Description

Function Introduction:
The thickness of die-cutting roller is 30mm. Balance adjustment, hard chromium plating.
The wall is high quality steel, the thickness is 50mm.
Soft roll has automatic grinding institutions, it can grind 3-4 times.
The line speed automatic compensate to ensure the size of every carton box is same.
Imported polyurethane cut soft capsule, install easily, the die-cutting time is 12 million times.
Mechanical soft roller left and right move to 40 mm, rubber mat wear equably.
Six levels grinding gear adopts 40 CrMinTi quality material.
Die-cutting roller is cylinder type automatic separate device.
The precision is ±0.5 mm.
The phase adopts microcomputer control can 360°phase adjust arbitrarily.
LCD touch screen realizes man-machine conversation.
The rotary die-cutting main machine adopts frequency control of motor speed.
Equipped with light, electric, air combined control system.

Option:
The rotary die-cutting machine can be optional the cardboard clean waste machine.
The front dam-board is manual adjustment, side dam-board is computer adjustment.
The lead roll has the slot rubber surface, prevent damaging the cardboard strength, increase the accuracy of feeding paper.
The back block box, push board is electric adjustment, can realize digital control.
The rotary die-cutting adopts PLC program control.
